Description & Specifications
Specifications
| Model | V1-BK-v1 |
| Case Type | Mid Tower |
| Color | Black |
| Body Material | SGCC |
| Front Panel Material | ABS |
| Steel Thickness | 0.8 mm |
| Motherboard Compatibility | ATX / Micro ATX / Mini-ITX |
| Case Dimensions (Internal) | 290 x 460 x 480 mm (W x H x D) |
| Case Dimensions (Overall) | 290 x 485.5 x 500 mm (W x H x D) |
| 3.5” Drive Bays | 2 Max. (2 x 3.5”/2.5″) |
| 2.5” Drive Bays | 6 Max. (4 x 2.5” and 2 x 2.5″/3.5”) |
| Expansion Slots | 7 |
| GPU Clearance | Supports GPU up to 395 mm (Without radiator in the front-right position) |
| CPU Cooler Clearance | Supports CPU cooler up to 170 mm |
| Air Cooling Support |
Front-Right: 120 mm x 3 or 140 mm x 2 or 160 mm x 2 (Max.) Top: 120 mm x 3 or 140 mm x 2 (Max.) Bottom: 120 mm x 3 (Max.) or 140 mm x 2 (Max.) Rear: 120 mm x 1 (Max.) |
| Liquid Cooling Support |
Front-Right: 120/140/240/280/360 mm Radiator (Optional) Top: 120/140/240/280/360 mm Radiator (Optional) Bottom: 120/140/240/280/360 mm Radiator (Optional) (140/280 Radiator: When M/B is at upper position; Not recommended at the bottom with liquid cooling) Rear: 120 mm Radiator (Optional) |
| Filters |
Top (Built-in) Front-Right (Removable) Side (Removable) Bottom (Removable) |
| I/O Ports |
USB 3.2 Gen 2x2 Type-C x 1 USB 3.2 Gen 1 Type-A x 2 Audio & Mic |
| Internal Cable Management Depth | 90 mm |
| Power Supply | ATX PSU (Including cables, up to 220 mm) (Optional) |
