COOLER MASTER V SFX PLATINUM 1300 230V ATX 3.0 PSU - 884102095146

• SMALL SIZE - V SFX Platinum are the most powerful SFX power supplies on the market & are designed specifically for mini-ITX (SFF) PC cases with their compact size (100x25x63.5mm); SFX to ATX bracket included if needed
• 80 PLUS PLATINUM EU 230V - 94% efficiency (under typical load at 230V) makes the 80 PLUS Platinum ideal for compact systems with high energy demand; V1300 offers 53% higher output power (26.8W/in³) than the PSU V850 SFX Gold
• COMPLETE ATX 3.0 SUPPORT - Equipped with a 12VHPWR connector that can provide a maximum of 600W to the latest 40 series GPUs; Fully modular cabling that allows clean case builds & improves internal ventilation
• Silent FDB Fan - 92mm Elite Smooth Dynamic Bearing (FDB) fan to keep temperature & noise minimum; Fan failure protection stops power if fan operation is disturbed
• BUILT TO LAST- The SFX Platinum V Series is built to last with exceptional component quality (100% Japanese elite capacitors) & is designed to maximize efficiency, heat dissipation & space; 10-year warranty

Modular- Fully Modular

PFC- Active PFC

Input Frequency- 50-60Hz

ErP 2014 Lot 3- Yes

ATX 24 Pin Connectors- 1

EPS 4+4 Pin Connectors- 1

CategoryAbove-  750W

EPS 8 Pin Connector- 1

Fan Bearing- FDB

Fan Size- 92mm

Power Good Signal100 - 150 ms

12VHPWR Connector- 1

Input Voltage Range- 230V

80 Plus- Platinum

MTBF>100,000 Hours

Operating Temperature- 0-50°C

SATA Connectors- 8

Peripheral 4 Pin Connectors- 4

Dimensions (L x W x H)100 x 125 x 63.5 mm

Protections- OVP

80 PLUS Rating- 80 PLUS Platinum EU 230V

Protections- OPP

Protections- SCP

ATX Version- SFX 12V Ver. 3.42

PCI-e 6+2 Pin Connectors- 3

Protections- UVP

ATX Version- ATX 3.0

Protections- OTP

Protections- OCP

Series- V SFX Series

Input Voltage- 200-240V

Protections- Surge and Inrush Protection

Regulatory- CCC

Regulatory- CE

Regulatory- EAC

Regulatory- cTUVus

Regulatory- FCC

Regulatory- BSMI

Efficiency- ≥ 94% @ Typical Load

Hold Up Time- ≥16ms at 60% Load

Regulatory- TUV

Input Current- 7.7A (Max.)

Regulatory- UKCA

Model- MPZ-D001-SFBP-B
