About this item
Storage Capacity: 14 TB
Wireless LAN: No
Drive Interface: SATA
Drive Type: Internal
All WD Purple drives are equipped with AllFrame technology, which improves ATA streaming to help reduce frame loss, improve overall video playback, and increase the number of hard drive bays supported within an NVR
WD Purple drives with AllFrame 4k technology feature a workload rating of up to 180TB/year - up to three times that of desktop drives - to handle the unique demands of modern video surveillance DVR and NVR systems
WD Purple hard drives are built with compatibility in mind, so you can quickly and seamlessly add capacity to your surveillance system.
As an industry-leading hard drive manufacturer, Western Digital stands behind their surveillance storage solutions with a 3-year limited warranty
Support for more than eight bays
The WD Purple Pro HDD, with OptiNAND technology in 22TB(1), delivers big capacity in a drive engineered for advanced, AI-enabled, always-on smart video recorders, appliances, and servers. | (1) 1TB = one trillion bytes. Actual user capacity may be less, depending on operating environment.Specific uses: Surveillance
Western Digital's exclusive AllFrame AI technology improves ATA streaming to help reduce frame loss and improve overall video playback.
WD Purple Pro drives are optimized to handle up to 64 single-stream HD cameras(2) as well as many of the latest smart cameras that transmit multiple streams. | (2) Single stream per camera @ 3.2Mbps (1080p, H.265, 25 fps). Results may vary depending on camera resolution, file format, frames per second, software, system settings, video quality, and other factors.
With a workload rating up to 550TB/year(3), these drives are built to keep up with heavy video data capture and analysis. | (3) Workload Rate is defined as the amount of user data transferred to or from the hard drive. Workload Rate is annualized (TB transferred ✕ (8760 / recorded power-on hours)). Workload Rate will vary depending on your hardware and software components and configurations.
The reliable WD Purple Pro is engineered with an MTBF of up to 2.5 million hours(4) for advanced smart video solutions that operate in 24/7 environments. | (4) Projected values. When final, MTBF, and AFR specifications will be based on a sample population and are estimated by statistical measurements and acceleration algorithms under typical operating conditions, workload of 220TB/year, and drive temperature of 40°C. Derating of MTBF and AFR will occur above these parameters, up to 550TB writes per year, and 65°C drive temperature. MTBF and AFR ratings do not predict an individual drive’s reliability and do not constitute a warranty.
