Standards and Protocols

Wi-Fi 7

IEEE 802.11be/ax 6 GHz

IEEE 802.11be/ax/ac/n/a 5 GHz

IEEE 802.11be/ax/n/b/g 2.4 GHz



WiFi Speeds

BE14000

6 GHz: 8647 Mbps (802.11be)

5 GHz: 4324 Mbps (802.11be)

2.4 GHz: 688 Mbps (802.11be)



WiFi Range

Broader Whole Home Coverage

TP-Link Mesh Technology

Optional Ethernet backhaul work together to link Deco units to provide seamless coverage



AI-Driven Mesh

Intelligently learns the network environment to provide ideal Wi-Fi unique to your home



8× High-Gain Antennas (Internal)

Multiple antennas form a signal-boosting array to cover more directions and large areas



Tri-Band

The greenfield 6 GHz band brings more bandwidth and faster speeds







WiFi Capacity

Very High

Tri-Band

Distribute devices to different bands for optimal performance



4×4 MU-MIMO

Simultaneously communicates with multiple MU-MIMO clients



OFDMA

Simultaneously communicates with multiple WiFi 7 clients



8 Streams

More than enough bandwidth for connected devices





Working Modes

Router Mode

Access Point Mode





Advanced Features

• Multi-Link Operation (MLO)

• 320 MHz Channel

• 4K-QAM

• Multi-RUs

• Works with Alexa and Google Assistant







SECURITY

Network Security

SPI Firewall

Access Control



HomeShield Security

Real-Time IoT Protection

Malicious Site Blocker

Intrusion Prevention System

DDoS Attack Prevention

Home Network Scanner







Guest Network

1× 6 GHz Guest Network

1× 5 GHz Guest Network

1× 2.4 GHz Guest Network

Effective Time

Bandwidth Control



WiFi Encryption

WPA-Personal

WPA2-Personal

WPA3-Personal



HARDWARE

Ethernet Ports

• 1× 10 Gbps

• 1× 2.5 Gbps

• 1× 1.0 Gbps



*Per Deco Unit

Supports WAN/LAN auto-sensing



USB Support

1× USB 3.0 Port

FTP Server

Media Server

Samba Server



Buttons

1× Reset Button

1× WPS
