SPECIFICATIONS
Graphics Engine:
-
AMD Radeon™ RX 7800 XT
Model Name:
-
RX7800XT 16G-L/OC/WHITE
Series:
-
Hellhound
Stream Processor:
-
3840 Units
Video Memory:
-
16GB GDDR6
Memory Speed:
-
19.5 Gbps
Memory Interface:
-
256-bit
Engine Clock(OC):
-
up to 2213MHz(Game)¹
-
up to 2520MHz(Boost)²
Engine Clock(STD/Silent):
-
up to 2124MHz(Game)¹
-
up to 2430MHz(Boost)²
Bus Standard:
-
PCIE 4.0
Standard Display Connectors:
-
1 x HDMI 2.1，3 x DisplayPort 2.1
(only 2x simultaneous DP2.1 connections can be supported)
Feature Support
DirectX® Support:
-
12
OpenGL:
-
4.6
AMD Eyefinity Technology:
-
Support
AMD Stream Technology:
-
Support
AMD Smart Access Memory:
-
Support
Maximum Resolution
DisplayPort:
-
7680×4320
HDMI:
-
7680×4320
Power Specs + Board Dimensions
Board Dimensions:
-
322mm*134mm*50mm
-
332mm*147mm*50mm(with bracket)
Slot:
-
2.5
Minimum System Power requirement (W):
-
750W³
Extension Power Connector:
-
Two 8-pin PCI Express Power connectors
