• SFX Form Factor: A SFX PSU is the ideal solution for mini-ITX builds. The included bracket makes this unit compatible with both SFX and ATX cases.
• Fully support ATX3.0: 12VHPWR connector with a compact 12Plus4 pin cable can pump up to 600W of power to a GPU via a single cable.
• 100% Japanese Capacitors: Implementing the highest quality of Japanese capacitors to increase efficiency and reduce ripple noise.
• Full-bridge LLC and DC-DC Technology: Designed in non-contact heat dissipation structure can reduce the switching losses of the power supply and improve the overall efficiency.
• Full-Modular Cabling: Modular cables reduce clutter, increase airflow, and improve overall efficiency and thermal performance.

Category- Above 750W

Modular- Fully Modular

PFC- Active PFC

Input Frequency- 50-60Hz

ErP 2014 Lot 3- Yes

ATX 24 Pin Connectors- 1

EPS 4+4 Pin Connectors- 1

80 PLUS Rating- 80 PLUS Platinum

EPS 8 Pin Connector- 1

Fan Bearing- FDB

Fan Size- 92mm

Power Good Signal- 100 - 150 ms

12VHPWR Connector- 1

Input Voltage Range- Full Range

MTBF>100,000 Hours

80 Plus- Platinum

Operating Temperature- 0-50°C

Input Voltage- 100-240V

SATA Connectors- 8

Peripheral 4 Pin Connectors- 4

Dimensions (L x W x H)100 x 125 x 63.5 mm

Protections- OVP

Protections- OPP

Protections- SCP

ATX Version- SFX 12V Ver. 3.42

PCI-e 6+2 Pin Connectors- 3

Protections- UVP

Protections- OTP

ATX Version- ATX 3.0

Protections- OCP

Series- V SFX Series

Protections- Surge and Inrush Protection

Regulatory- CCC

Regulatory- CE

Regulatory- EAC

Regulatory- cTUVus

Regulatory- FCC

Efficiency≥ 92% @ Typical Load

Regulatory- BSMI

Hold Up Time- ≥16ms at 70% Load

Regulatory- TUV

Input Current- 14-6.5A

Regulatory- UKCA

Model- MPZ-B001-SFAP-B
