• DIY PC CASE - The award-winning PC case comes in a flat pack, makes extreme customisation possible & fits full-tower features; Modify the case with the included GEM mini cable manager and 3D print custom parts (See more plans on Printables.com)
• FULLY MODULAR - Super easy build with swappable panels, handle, side radiator bracket, multiple PSU mounts & storage options; Versatile feet for a standing or laying orientation, enabling easy hardware access & a tempered glass panel showcases the build
• HIGH THERMAL PERFORMANCE - The interior supports up to 8 fans ( 7 x 140 mm + 1 x 120 mm) for air cooling & various radiator options ( 2 x 280 mm + 1 x 240 mm) for AIO liquid cooling; Includes pre-installed Sickleflow White 120 mm fan (PWM, 1800RPM)
• IMPRESSIVE CLEARANCES - Accommodates E-ATX (max 296 mm w/ SFX PSU), ATX, micro-ATX and ITX motherboards; CPU coolers up to 172 mm in height; Graphics cards (vertical GFX/GPU holder included) up to 365 mm in length; Up to an ATX PSU (173-332 mm in length)
• CONNECTIVITY - USB 3.2 Gen 2x2 Type-C port (20 GB/s transfer speed) 2 x USB 3.2 Gen 1 Type-A ports, 1 x audio jack, 1 x Power button; Cleaner cable management with up to 5 spots & 29-32 mm allocated space behind the MB tray

Radiator Support - Bottom120mm

Radiator Support - Rear120mm

Dust Filters- Top

Dust Filters- Front

Warranty- 2 years

Radiator Support - Bottom140mm

Size- Mid Tower

Exterior Color- Black

Materials - ExteriorSteel

Fan Support - Left side2x 120/140mm

Radiator Support - Left side120mm

Radiator Support - Left side140mm

Materials - ExteriorPlastic

Exterior Color- White

Power Supply Support- ATX

Radiator Support - Bottom240mm

Dust Filters- Bottom

3.5" Drive Bays- 4

Fan Support - Rear1x 120mm

Radiator Support - Top280mm

Radiator Support - Left side240mm

Gem Mini- QUBE 500 Black: x1

Gem Mini- QUBE 500 White: x1

Handle- QUBE 500 Black: x1

Radiator Support - Left side280mm

I/O Panel - Audio In / Out1x 3.5mm Combo

I/O Panel - USB Ports2x USB 3.2 Gen 1 Type A

Dust Filters- Right side

Materials - ExteriorTempered Glass

Radiator Support - Top240mm

Fan Support - Bottom2x 120/140mm

Fan Support - Top2x 120/140mm

I/O Panel - USB Ports1x USB 3.2 Gen 2 x 2 Type C

HandleQUBE 500 White: x1

Materials - Left Side PanelGrey TG + Steel

Radiator Support - Front140mm

Expansion Slots-7

Radiator Support - Top140mm

Motherboard Support- ATX

Motherboard SupportMicro-  ATX

Radiator Support - Top120mm

Radiator Support - Front120mm

2.5" Drive Bays- 3

Radiator Support - Bottom280mm

Motherboard Support- ITX

Series- QUBE Series

Cable Routing - Behind Motherboard Tray29-32mm

Motherboard Support- E-ATX (Width up to 296mm w/ SFX PSU, up to 273 w/ ATX PSU)

Power Supply Support- SFX

Power Supply Support- SFX-L

Radiator Support - Front(240/280mm w/ PSU in bottom)

Volume- 33.44L (excl. Protrusions)

Radiator Support - Top(280mm can be used within 53mm thickness)

Clearance - PSU173mm to first GPU slot, 216 maximum space (w/o cable management space)

Clearance - PSU332mm space mounted in bottom (w/o cable management space)

Clearance - CPU Cooler164mm-172mm (Remove the water cooling bracket)

Fan Support - Front1x 120/140mm (x2 if PSU is mounted in bottom)

Pre-installed Fans - RearQUBE 500 Black: 1x SickleFlow 120 Black PWM (1800 RPM)

Pre-installed Fans - RearQUBE 500 White: 1x SickleFlow 120 White PWM (1800 RPM)

Clearance - GFX365mm

Dimensions (L x W x H)406 x 231 x 415mm (Incl. Protrusions)

Dimensions (L x W x H)380 x 231 x 381mm (excl. Protrusions)

Model Number- QUBE 500 Black: Q500-KGNN-S01, QUBE 500 White: Q500-WGNN-S01
