ATEN VS481C-AT-E 4-Port True 4K HDMI Switch - 672792008221

Switches

• DIP

          Auto Switch ON/OFF

• Max. Distance

          5M at 4096 x 2160 / 3840 x 2160 @ 60Hz (4:4:4)

Video Output

• Interfaces

          1 x HDMI Type A Female (Black)

• Impedance

          100 Ω

• Max. Distance

          5M at 4096 x 2160 / 3840 x 2160 @ 60Hz (4:4:4)

Video

• Max. Data Rate

          18 Gbps (6 Gbps Per Lane)

• Max. Pixel Clock

          600 MHz

• Compliance

          HDMI 2.0 (3D, Deep Color, 4K)
          HDCP 2.2
          Consumer Electronics Control (CEC)

• Max. Resolution

          4096 x 2160 / 3840 x 2160 @ 60Hz (4:4:4)

• Control

          RS-232    Connector：1 x DB-9 Female (Black)
          Baud Rate：19200 / Data Bits：8 / Stop Bits：1 / Parity：NO / Flow Control：NO

• IR

         1 x Mini Stereo Jack Female (Black)
         1 x IR Receiver

Connectors

• Power

          1 x DC Jack (with locking)

• Power Consumption

          DC5V:0.924W:20BTU/h

Note:
● The measurement in Watts indicates the typical power consumption of the device with no external loading.
● The measurement in BTU/h indicates the power consumption of the device when it is fully loaded.

Environmental

• Operating Temperature

          0-40 °C

• Storage Temperature

         -20 - 60 °C

• Humidity

          0 - 80% RH, Non-Condensing

• Physical Properties

          Housing
          Metal

• Weight

          0.47 kg ( 1.04 lb )

• Dimensions (L x W x H)

          20.00 x 8.21 x 2.50 cm
          (7.87 x 3.23 x 0.98 in.)

• Carton Lot

          10 pcs

• Package Contents

          1x VS481C 4-Port True 4K HDMI Switch
          1x Power Adapter
          1x IR Remote Control Unit
          1x HDMI Cable
          1x User Instructions

2 Years
