Description & Specifications
| Model Number | TUF Gaming AX4200 |
| Network Standard | IEEE 802.11a |
| IEEE 802.11b | |
| IEEE 802.11g | |
| WiFi 4 (802.11n) | |
| WiFi 5 (802.11ac) | |
| WiFi 6 (802.11ax) | |
| IPv4 | |
| IPv6 | |
| Product Segment | AX4200 ultimate AX performance: 574 3603 Mbps |
| AX technology | Yes |
| Data Rate | 802.11a : up to 54 Mbps |
| 802.11b : up to 11 Mbps | |
| 802.11g : up to 54 Mbps | |
| WiFi 6 (802.11ax) (2.4GHz) : up to 574 Mbps | |
| WiFi 6 (802.11ax) (5GHz) : up to 3603 Mbps | |
| Antenna | External antenna x 4 |
| Transmit/Receive | 2.4GHz 2×2 |
| 5GHz 3×3 | |
| Processor | 2.0 GHz quad-core processor |
| Memory | 256 MB Flash |
| 512 MB RAM | |
| Boosts speed | OFDMA (Orthogonal Frequency Division Multiple Access) |
| Beamforming: standard-based and universal | |
| 1024-QAM high data rate | |
| 20/40/80/160 MHz bandwidth | |
| Operating Frequency | 2.4GHz / 5GHz |
| Ports | RJ45 for 2.5 Gigabits BaseT for WAN x 1, |
| RJ45 for Gigabits BaseT for LAN x 4, | |
| USB 3.2 Gen 1 x 1, | |
| Button | WPS Button, Reset Button, Power Button |
| LED Indicator | Power x 1 |
| 2.4G x 1 | |
| 5G x 1 | |
| LAN x 4 | |
| WAN x 1 | |
| Power Supply | AC Input : 100V~240V (50~60Hz) |
| DC Output : 12 V with max. 2.5 A current | |
| Package content | TUF Gaming AX4200 Dual Band WiFi 6 router |
| RJ-45 cable | |
| Power adapter | |
| Quick Start Guide | |
| Warranty card | |
| Product Weight (g) | 547.4 g |
| AiMesh | AiMesh |
| Primary AiMesh router | |
| AiMesh node | |
| Router APP | ASUS Router APP |
| Game | Game Boost / Acceleration |
| AiProtection | AiProtection Pro |
| AiProtection | |
| Malicious site blocking | |
| Two-Way IPS | |
| Infected Device Prevention and Blocking | |
| Parental Control | Parental Control |
| Parental Control Customized Internet schedule | |
| Traffic Control | Adaptive QoS |
| Bandwidth Monitor | |
| Bandwidth limiter | |
| Maximum Bandwidth limiter rule : 32 | |
| Traditional QoS | |
| Maximum Traditional QoS rule : 32 | |
| Traffic Monitor | |
| Real-time traffic monitor | |
| Wired Traffic Monitor | |
| Wireless Traffic Monitor | |
| Traffic Analyzer | |
| Traffic analysis period : Daily, Weekly, Monthly | |
| Website history | |
| Wireless | IPv6 |
| Wi-Fi Encryption : WPS support, WPA/WPA2/WPA3-Personal, WPA/WPA2-Enterprise | |
| UTF-8 SSID | |
| Guest Network | |
| Maximum Guest Network rule : 2.4GHz x3, 5GHz x3 | |
| Guest Network Connection time limit | |
| WPS | |
| WiFi MAC address filter | |
| Maximum MAC filters : 64 | |
| Wireless scheduler | |
| Airtime fairness | |
| RADIUS Client | |
| Universal beamforming | |
| Explicit beamforming | |
| WAN | Internet connection Type : PPPoE, PPTP, L2TP, Automatic IP, Static IP |
| 3G/4G LTE dongle | |
| Android tethering | |
| Port forwarding | |
| Maximum port forwarding rule : 64 | |
| Port triggering | |
| Maximum port triggering rule : 32 | |
| DMZ | |
| DDNS | |
| NAT Passthrough : PPTP Pass-Through, L2TP Pass-Through, IPSec Pass-Through, RTSP Pass-Through, H.323 Pass-Through, SIP Pass-Through, PPPoE relay | |
| Safe browsing | |
| DNS-over-TLS | |
| LAN | DHCP Server |
| IPTV | |
| LAN Link Aggregation | |
| Manually assign IP address | |
| Maximum manually assign IP address rule : 64 | |
| VPN | VPN Client L2TP |
| VPN Client OVPN | |
| VPN Client PPTP | |
| VPN Client WireGuard | |
| VPN Server IPSec | |
| VPN Server OVPN | |
| VPN Server PPTP | |
| VPN Server WireGuard | |
| VPN Fusion | |
| USB application | File System : HFS , NTFS, vFAT, ext2, ext3, ext4 |
| 3G/4G LTE dongle | |
| Safely Remove disk | |
| AiCloud | |
| Download master | |
| AiDisk | |
| Media Server | |
| Time Machine | |
| Samba Server | |
| FTP Server | |
| Shared Folder privileges | |
| Administration | Operating mode : Wireless router mode |
| Access point mode | |
| Media bridge mode | |
| Operating system : ASUSWRT | |
| Free OS upgrade | |
| Firewall | |
| Maximum Firewall keyword filter : 64 | |
| Maximum Firewall network service filter : 32 | |
| Maximum Firewall URL filter : 64 | |
| SSH | |
| Wake on LAN (WOL) | |
| Configuration backup and restore | |
| Diagnosis tools | |
| Feedback system | |
| System log | |
| New Device Connect Notification | |
| Login Captcha | |
| Connection Diagnosis | |
| Security Scan | |
| Auto Firmware Update | |
| Warranty | 3 Years |
