Network Standard
WiFi 7 (802.11be)
IPv4
IPv6

Product Segment
BE6800 ultimate BE performance : 1032+5764 Mbps

WiFi Data Rate
WiFi 7 (802.11be) (2.4GHz): up to 1032 Mbps
WiFi 7 (802.11be) (5GHz): up to 5764 Mbps

Antenna
External antenna x 3； Internal antenna x 1

Transmit / Receive
2.4GHz 3x3
5GHz 4x4

Processor
2.6GHz quad-core processor

Memory
256 MB Flash and 1 GB RAM

Boosts Speed
OFDMA (Orthogonal Frequency Division Multiple Access)
Beamforming: standard-based and universal
4096-QAM high data rate
20/40/80/160 MHz bandwidth

Operating Frequency
2.4 GHz
5 GHz

Operating Mode
Wireless Router Mode
AiMesh Node Mode
Access Point Mode
Media Bridge Mode
Repeater Mode

I/O Ports
1 x 10G for WAN/LAN, 1 x 2.5G for WAN/LAN, 3 x 2.5G for LAN, USB 3.2 Gen1 x1, USB 2.0 Gen1 x1

Buttons
WPS Button, Reset Button, Power Switch, LED on/off Button

LED Indicator
WAN x1
10G Port x1
LAN x4
USB x1
2.4GHz x1
5GHz x1
Power x1

Power Supply
AC Input : 110V~240V(50~60Hz)
DC Output : 12 V with max. 5 A current ； 19.5 V with max. 2.31 A current

Package Content
RT-BE86U WiFi router
RJ-45 cable
Power adapter
Quick Start Guide
Warranty card

Product Weight (g)
854 g

Product Dimensions
235*90*316 mm

AiMesh
AiMesh
Primary AiMesh Router
AiMesh Node

Game
Mobile Game Mode
Gear Accelerator
OpenNAT (Game Profile)
Gaming Port

Parental Control
"Allow you to block access to unwanted websites and apps."
Web & Apps Filters
Time Scheduling
Safe Browsing
Customized Internet Schedule
Maximum Parental Control Profile : 64
Maximum Parental Control Content Cilter Rule : 64

Guest Network
"You can create additional networks for different purposes, these networks are separate from the main network domain, to provide enhanced security, and create comprehensive network environment with customized settings."
Support Guest Network Pro
Maximum Guest Network Rule : 2.4 GHz + 5 GHz : 5
Guest Network Connection Time Limit
Guest Network Pro Encryption : Open system, WPA/WPA2-Personal/WPA3-Personal

Security
AiProtection
VPN
WPA3 Personal, WPA2 Personal, WPA Personal, WPA Enterprise, WPA2 Enterprise, WPA3 Enterprise, Open System & OWE
WPS
Let's Encrypt
DNS-over-TLS
SSH
Security Scan
Firewall
Maximum Firewall Keyword Filter : 64
Maximum Firewall Network Service Filter : 32
Maximum Firewall URL Filter : 64

AiProtection
AiProtection Pro
Router Security Assessment
Malicious Site Blocking
Two-Way IPS
Infected Device Prevention and Blocking

VPN
Instant Guard
VPN Client L2TP
VPN Client Open VPN
VPN Client PPTP
VPN Client WireGuard
VPN Server IPSec
VPN Server Open VPN
VPN Server PPTP
VPN Server WireGuard
VPN Fusion
Support Surfshark

Traffic Control
Adaptive QoS
Bandwidth Monitor
Bandwidth Limiter
-- Maximum Bandwidth Limiter Rule : 32
Traditional QoS
Traffic Monitor
Real-time Traffic Monitor
Wired Traffic Monitor
Wireless Traffic Monitor
Traffic Analyzer

3 Years
