ASUS ROG STRIX B850-G GAMING WIFI MOTHERBOARD - 197105823631

CPUAMD Socket AM5 for AMD Ryzen™ 9000 & 8000 & 7000 Series Desktop Processors

ChipsetAMD B850 Chipset

Memory2 x DIMM slots, max. 128GB, DDR5

Supports up to

8200+MT/s(OC) with Ryzen™ 9000 Series Processors,

9600+MT/s(OC) with Ryzen™ 8000 Series Processors,

8000+MT/s(OC) with Ryzen™ 7000 Series Processors,

ECC and Non-ECC Un-buffered DIMM*

Dual channel memory architecture

Supports AMD Extended Profiles for Overclocking (EXPO™)

ASUS Enhanced Memory Profile (AEMP)

Graphics1 x HDMI™ port***

1 x USB 10Gbps ports support USB Type-C® display outputs

Expansion SlotsAMD Ryzen™ 9000 & 7000 Series Desktop Processors

1 x PCIe 5.0 x16 slot with Q-Release Slim

AMD Ryzen™ 8000 Series Desktop Processors

1 x PCIe 4.0 x16 slot with Q-Rlease Slim

- To ensure compatibility of the device installed, please refer to https://www.asus.com/support/download-center/ for the list of supported peripherals.

StorageTotal supports 2 x M.2 slots and 2 x SATA 6Gb/s ports

AMD Ryzen™ 7000 & 9000 Series Desktop Processors

M.2_1 (Key M), type 2242/2260/2280 (supports PCIe 5.0x4 mode)

M.2_2 (Key M), type 2242/2260/2280 (supports PCIe 5.0 x4 mode)

AMD Ryzen™ 8000 Series Desktop Processors

M.2_1 (Key M), type 2242/2260/2280 (supports PCIe 4.0x4 mode)

M.2_2 (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode)*

* Specifications vary by CPU types.

Ethernet1 x Intel® 2.5Gb Ethernet

ASUS LANGuard

Wireless & BluetoothWi-Fi 7*

2x2 Wi-Fi 7 (802.11be)

Supports 2.4/5/6GHz frequency band

Supports Wi-Fi 7 160MHz bandwidth, up to 2.9Gbps transfer rate.

Bluetooth® v5.4

USBRear USB (Total 8 ports)

1 x USB 20Gbps port(s) (1 x USB Type-C®)

5 x USB 10Gbps port(s) (4 x Type-A + 1 x USB Type-C®)

2 x USB 2.0 port(s) (2 x Type-A)

Front USB (Total 5 ports)

1 x USB 10Gbps

1 x USB 5Gbps header(s) support(s) 2 additional USB 5Gbps ports

1 x USB 2.0 header(s) support(s) 2 additional USB 2.0 ports

USB Type-C® power delivery output: max. 5V/3A

AudioROG SupremeFX 7.1 Surround Sound High Definition Audio CODEC ALC4080*

- Impedance sense for front and rear headphone outputs

- Supports: Jack-detection, Multi-streaming, Front Panel MIC Jack-retasking

- High quality 120 dB SNR stereo playback output and 110 dB SNR recording input

- Supports up to 32-Bit/384 kHz playback on front panel

BIOS256 Mb Flash ROM, UEFI AMI BIOS

ManageabilityWOL by PME, PXE

AccessoriesCables

2 x SATA 6Gb/s cables

Miscellaneous

1 x ASUS WiFi Q-Antenna

1 x Cable ties package

1 x M.2 backplate Q-Latch package(s)

1 x M.2 Q-Slide package

1 x ROG key chain

1 x ROG Strix stickers

1 x M.2 backplate rubber package(s)

Documentation

1 x Quick start guide

Operating SystemWindows 11

Form FactorMini-ITX Form Factor

6.7 inch x 6.7 inch (17 cm x 17 cm)
